Febcode Manual¶

Introduction¶

Febcode is a domain-specific language (DSL) designed for extending and customizing simulations with FEBio. Its primary goal is to allow users to define mathematical models, user-defined behavior, and custom logic in a concise, expressive, and computationally efficient way. It provides an alternative approach to extending FEBio with plugins. Plugins often introduce significant overhead in development, compilation, and maintenance. Febcode removes this barrier by providing:

A lightweight scripting interface
Strong mathematical expressiveness
Built-in automatic differentiation (AD)
Seamless integration with FEBio’s feature system

This enables rapid prototyping, easier experimentation, and more maintainable simulation workflows. However, febcode scripts are somewhat limited in the type of extensions that can be implemented. For more complex extensions plugins remain the preferred approach.

Approach¶

Febcode is an interpreted language that is compiled to bytecode. Briefly, the following steps are executed to compile the code from input text to bytecode:

Tokenization: convert the raw input text to a stream of tokens. Each token represents an atomic element of the language, like keywords, numbers, variable names, operations, etc.
Parsing: Process the stream of tokens and construct an Abstract Syntax Tree (AST). The AST represents the code as a tree of statements and expressions.
Compilation: The AST is now compiled to bytecode by recursively compiling each statement and expression in the tree.
Execution: The resulting bytecode is executed at runtime by a special component, called the virtual machine (VM).

To ensure optimal performance, febcode uses a static stack size. The stack size is determined during compilation. Since the stack size is fixed, no expensive memory allocations need to happen during execution of the bytecode. To guarantee that the stack size is known in advance, febcode uses static types so that the required memory of all variables and expressions is known at compile time. In addition, the language enforces some special rules that ensure the stack size is static. The most important rule is that user-defined functions cannot be called recursively.

Core Capabilities¶

Febcode is a relatively simple scripting language, focused on performance and safe execution within FEBio's multithreaded environment. For the most part, it uses a C-like syntax.

The febcode language supports a static type system tailored to the needs of implementing mathematical expressions. It also offers some simple control flow.

Scalar and Vector Math¶

Boolean: bool
Scalars: int, double
Vectors: vec2, vec3
Matrices: mat2, mat3

Operations include:

Arithmetic: +, -, *, /, **
Dot product: * (when operands are vec2 or vec3)
Matrix-vector multiplication: * (when operands make sense)

Example:

vec3 a = vec3(1, 2, 3);
vec3 b = vec3(4, 5, 6);
double d = a*b; // dot product

mat3 A = mat3(1.0);
vec3 v = A*b; // matrix-vector multiplication

Variables¶

Variables are declared by first specifying the type, followed by a valid name. Valid names start with a letter (lower or upper case), followed by letters, numbers, or underscores (_). Here are examples of some valid variable declarations.

double a;
int i0;
vec2 v_0;

Note that user-defined variables cannot start with an underscore (_). This is because variables that start with underscores have special meaning (see below).

Input Variables¶

Using the in keyword, users can label certain variables as input variables. These are special variables for which the value is specified in the FEBio input file, not in the script. This allows users to expose script variables to the rest of FEBio's ecosystem. (Users can use parameter optimization on these variables, set the variables in FEBio Studio, etc.)

in double a;

The FEBio input file defines the value for these variables using a special syntax.

<add_param name="a" data_type="double">1.23</add_param>

Aside from the different syntax, these parameters are treated as any other FEBio parameters. For instance, users can attach load controllers or maps for these parameters.

Injected Variables¶

Injected variables are special variables that are provided by FEBio and typically contain the value of solution variables at the point where the script is evaluated. Injected variables will always start with an underscore. Although the exact list of the injected variables depends on the context, many scripted model components offer these injected variables.

_time: the current time
_pos0: the position of the material point in the reference configuration.
_pos : the position of the material point in the current configuration.

Functions¶

Febcode supports user-defined functions:

double add(double x, double y)
{
    return x + y;
}

Note that febcode functions cannot be called recursively. This limitation is a consequence of the need to have a static stack size that can be determined at compile time. A static stack size avoids expensive memory re-allocations during the execution of the script.

Febcode also supports native functions, including many commonly used mathematical functions.

abs
acos
acosh
asin
asinh
atan
atanh
cos
cosh
exp
log
log10
sin
sinh
sqrt
tan
tanh

Example:

double f = sin(x) * exp(y);

It also supports native functions that operate on vectors and matrices:

functions	description
`dot`	evaluates the dot product between two `vec2` or `vec3` variables.
`cross`	evaluates the cross product between two `vec3` variables.
`outer`	returns a `mat2` (`mat3`) that is the outer product between two `vec2`(`vec3`) variables.
`length`	calculate the length of a `vec2` or `vec3` variables.
`normalize`	returns a normalized (i.e. unit) vector of a `vec2` and `vec3` variables.
`transpose`	returns the transposed of a `mat2` or `mat3` variable.
`inverse`	returns the inverse of a `mat2` or `mat3` variable.

Example

mat3 A = transpose(B); // take the transpose of the mat3 B

Control Flow¶

The following control flow elements are supported:

If Statements¶

If statements allow branching based on logical criteria. They are defined using the if keyword. If statements can also contain an optional else branch that will be executed if the condition of the if statement evaluates to false.

Syntax:

if (condition)
{
    // branch executed if condition evaluates to true
}
else // optional
{
    // branch executed if condition evaluates to false
}

While Statements¶

A while statement repeatedly executes a block of code as long as a given condition remains true.

Syntax:

while (condition)
{
    // body
}

The condition is evaluated before each iteration. If the condition is true, the loop body executes. If the condition is false, the loop terminates. If the condition never becomes false, the loop runs indefinitely.

Example:

int i = 0;
while (i < 5)
{
    i = i + 1;
}

For Statements¶

A for statement is a control flow construct used to execute a loop with explicit initialization, condition checking, and iteration.

Syntax:

for (initialization; condition; update)
{
    // body
}

The initialization runs once at the start. The condition is evaluated before each iteration. If the condition is true, the loop body executes. After each iteration, the update expression runs. The loop ends when the condition becomes false.

Example:

for (int i = 0; i < 5; i = i + 1)
{
    // executes 5 times
}

Return Statement¶

A return statement terminates the execution of a function or script and optionally provides a value back to the caller.

Syntax:

return expression;

It's important to know that the expected return type is determined by the model component that uses the script. For instance, for a pressure script, the return value is the pressure value at the material point. Since the pressure is a scalar, the return type must be double. During compilation, FEBio checks that the return type is correct.

Automatic Differentiation (AD)¶

Febcode scripts can depend on the solution variables of the problem (using injected variables). This usually implies that it needs a contribution to the global stiffness matrix. The contributions require the evaluation of the derivative of the script with respect to the solution variable. To free the user of having to provide these derivatives, febcode implements automatic differentiation (AD) as a a core feature.

Approach¶

Febcode uses symbolic differentiation over the AST, not numerical or dual-number methods. This approach enables exact derivative computation of expressions without numerical approximation.

Key steps:

Traverse AST recursively
Apply differentiation rules per AST node
Simplify the resulting expression

The result is a modified AST that represents the code for evaluating the derivative of the original script. This derivative AST is now compiled like the original code and used to evaluate the derivatives during the stiffness matrix computation.

Using febcode in FEBio¶

To use febcode in FEBio you need to add a model component that uses a script to define its behavior. These components typically have the word script in it. (For instance, pressure script, body force script.) These components define the script property where you define the script's name and input variables.

Example:

<script name="MyScript">
    <add_param name="a" data_type="double" lc="1">3.14</add_param>
</script>

The code for the script is defined in the Scripts section of the input file. Each script is defined using the script child element. This element takes the name as the script as an attribute. The code for the script is defined as the value for the element.

Example:

<Scripts>
    <script name="MyScript"><![CDATA[
        in double a;
        return a**2;
    ]]></script>
</Scripts>

Note that the value is defined via a <![CDATA[]]> section. This is necessary since the code can contain special xml formatting characters (e.g. <) that can confuse xml readers. Any text in a <![CDATA[]]> section will be read as raw text.

For Developers¶

This section describes how you can make use of scripts in your plugins.

First, create a new class that inherits from FEScripted. This is a template class that takes the FEBio base class as a template argument. Make sure to pass the FEModel class to this base class. For example,

class MyScriptedFEature : public FEScripted<FESurfaceLoad>
{
    MyScriptedFEature(FEModel* fem) : FEScripted<FESurfaceLoad>(fem) {}
};

The FEScripted base class will automatically add a new script property to the plugin class. Users will use this property to define the script and the input parameters to the script.

The next step is to define the script context, which defines the expected return type of the script and the list of injected variables. It is advised to set the script context in the constructor of the plugin class.

MyScriptedFEature::MyScriptedFEature(FEModel* fem) : FEScripted<FESurfaceLoad>(fem)
{
    ScriptContext sc;
    sc.returnType = FEValueType::Double; // script should return a double variable.
    sc.addVariable("pos", FEValueType::Vec3d, true); // add pos as an differentiable injected variable.
    sc.addVariable("time", FEValueType::Double, false); // add time as a constant injected variable.
    SetScriptContext(sc);
}

When it's time to evaluate the script, use the FEScripted::Value method. This function takes two parameters, a FEMaterialPoint and a vector of FEValue variables that contain the values of the injected variables. Make sure that the size and order of the vector matches the list of injected variables defined in the script context.

vector<FEValue> vars(2);
vars[0] = mp.m_rt;
vars[1] = GetTimeInfo().currentTime;

double P = Value(mp, vars).toDouble();

The Value function will return a FEValue variant that can be used to extract the value. You can use the to<type> methods to extract the value of the correct type.

FEValue v;
bool b = v.toBool();
int i = v.toInt();
double a = v.toDouble();
vec2d v2 = v.toVec2d();
vec3d v3 = v.toVec3d();
mat2d m2 = v.toMat2d();
mat3d m3 = v.toMat3d();

Similarly, to evaluate derivatives, you can use the DerivValue method. In addition to a FEMaterialPoint and a std::vector<FEValue> parameter, it also takes an index parameter that indicates which derivative you want. The index is the index of the injected variable as defined in the script's context. You can query whether the script has a non-zero derivative using the HasDerivative method.

vec3d gradP(0,0,0); // gradient of pressure
if (HasDerivative(0)) // do we have a derivative w.r.t. position?
{
    // prepare values for injected variables.
    vector<FEValue> vars(2);
    vars[0] = mp.m_rt;
    vars[1] = GetTimeInfo().currentTime;

    gradP = Value(mp, vars).toVec3d();
}
return gradP;
